Zomax’s explosion-proof overhead cranes are built for hazardous environments, featuring flameproof enclosures and insulated components to ensure safety. With lifting capacities up to 320 tons and customizable single or double girder designs, they offer reliable, high-performance solutions tailored to demanding industrial applications.
Contact us, and our engineers will work closely with you to deliver a crane solution precisely tailored to your specific needs.
Explosion-Proof Bridge Cranes are specialized lifting systems designed for operations in hazardous environments where flammable gases, vapors, or dusts may be present. These cranes feature sealed electrical systems and explosion-proof components to prevent ignition sources, ensuring safe and reliable operation in explosive atmospheres.
Explosion-proof cranes help reduce the risk of explosions caused by electrical failures or mechanical sparks during lifting operations. Zomax cranes meet the stringent industry standards for hazardous environments, aimed at protecting personnel, property, and production safety. Whether you are operating in a chemical plant, paint booth, or processing facility, our team can help you select and deliver high-performance solutions that comply with regulations.
Electrical components and motors designed and built to explosion-proof regulations
Ergonomic user interface
Innovative mechanical configuration prevents sparking
Class H insulation, IP65 protection for electrical enclosures and IP66 for motors
International EX-proof certification: ATEX, CSA, CCC and IECEx for gas and dust
Accessible maintenance points
Precise and secure movement
Optional EX-proof extras to satisfy diverse requirements
| Lifting capacity | Up to 320 tons |
| Lifting height | Tailored |
| Span | Tailored |
| Crane type | Single girder or double girder |
| Trolley type | Hoist trolley or Open winch trolley |
| Girder design | Box girder |
| Explosion-proof level | ExdIIBT4 or ExdIICT4 |
| Rated voltage： | 220V/380V/400V/415V/660V, 50-60Hz, 3ph AC |
| Working class | A3-A8 |
| Temperature | Standard temperature: -20°C - +40°C. |
| Control options | Pendant / Remote / Cabin |
| Environment | Indoors |
Easy load and safe handling with outstanding performance
Increased productivity
Decreased downtime
Minimized risk of ignition under standard operating conditions
Shorter maintenance breaks with service-friendly service technology
Easily adaptable to various needs
High level of safety
Reliable in challenging environments
Ideal for industries like chemicals, wood and oil
All hoist and crane systems are fully tested for safety and reliability
Crane Body: The core structure, responsible for lifting and moving materials, consists of a crossbeam, bridge frame, motor, reducer, and brake.
Trolley: Handles lifting and movement, comprising a frame, motor, transmission system, and brake, selected based on load size and weight.
Main Beam: Supports the trolley and crane, bearing heavy loads, with customizable cross-sectional shapes.
Steel Wire Rope: A key lifting component made of multiple steel wire strands for load carrying.
Other Components: Includes steel structure, counterweight, limiters, hydraulic and electrical systems, and a control console.
Explosion-proof cranes are designed to operate safely in hazardous environments where flammable gases, vapors, or combustible dusts are present. These cranes can be customized according to specific safety ratings and operational requirements to ensure compliance with industry standards and workplace safety regulations.
Chemical Plants
Petroleum Refineries
Wood Processing Facilities
Paint Shops
Grain and Flour Mills
Wastewater Treatment Plants
Pharmaceutical Manufacturing
We are dedicated to delivering top-tier explosion-proof lifting solutions that adhere to the strictest safety standards. Our explosion-proof single-girder cranes are engineered for dependable performance in hazardous environments, guaranteeing safe operations and enduring reliability. Leveraging our extensive export experience and robust global service network, we provide comprehensive professional support, from consultation to installation, positioning ourselves as your trusted partner for secure and efficient lifting operations.
Installation and Commissioning:
Coordinate with the customer to schedule the installation of the crane by qualified Zomax technicians at the customer's site.
Oversee the installation process to ensure it is carried out correctly, safely, and on schedule.
Conduct a thorough commissioning of the crane to verify its functionality and performance, and provide hands-on training for operators.
On-site Training: Offer additional on-site training sessions for operators, maintenance staff, and supervisors, customized to their specific roles and responsibilities.
Provide safety training and best practices for operating and maintaining Zomax cranes to prevent accidents and optimize efficiency.
Post-Installation Support:
Ensure smooth crane operation from the day of installation and conduct follow-up visits immediately after installation.
Address any questions or concerns raised by the customer, whether related to crane performance or operational efficiency.
Provide detailed handover documentation, including equipment manuals, maintenance schedules, and technical support contact information.
Explosion-proof cranes are designed for hazardous environments where flammable gases, vapors, or dust are present. Key features include:
Sealed electrical components and motors to prevent sparks
Flameproof enclosures (Ex d)
Anti-sparking hooks and components
Compliance with ATEX, IECEx, or local hazardous area standards
Explosion-proof cranes are rated for different zones:
Zone 0 / 20: Continuous explosive atmosphere (rarely used for cranes)
Zone 1 / 21: Likely explosive atmosphere occasionally
Zone 2 / 22: Not likely, but possible under abnormal conditions
Calculate the heaviest load, lifting height, and span. Consider:
Single vs. double girder cranes
Frequency of lifting (duty cycle)
Load shape (drums, barrels, chemicals)
Explosion-proof cranes often use Ex motors, explosion-proof hoists, and sealed control panels. Options include:
Pendant control stations with flameproof enclosures
Wireless or radio remote controls designed for hazardous zones
Emergency stop features for high-risk operations
Regular maintenance is crucial:
Check seals and enclosures for damage
Inspect motors and wiring for heat buildup or corrosion
Follow strict documentation procedures for hazardous area maintenance
Selecting a crane with modular components simplifies maintenance without compromising safety.
Explosion-proof cranes often include emergency stop, anti-sway, and load limiters
Operator training for hazardous zones is essential
Choose designs with visual and audible alarms for safe operation
